PUREHEAT HEATER SPARE PARTS

PureHeat - Pure Bliss


DUE TO CHANGES IN MANUFACTURING COMPONENTS & COMPANIES, PLEASE TAKE NOTE :

CURRENT SPARES MAY NOT FIT UNITS MANUFACTURED PRIOR TO 2014
NOT ALL SPARE PARTS ARE AVAILABLE FOR SUPERSEDED UNITS


* Availability of superseded models spare parts changes daily *

If spares are not available, a new heater will be required
SPARE PARTS ARE NON RETURNABLE/NON REFUNDABLE FOR INCORRECT CHOICE OR CHANGE OF MIND

ALL ELECTRICAL ITEMS SHOULD BE ASSESSED, MAINTAINED & SERVICED BY LICENSED ELECTRICIANS ONLY

PART NUMBER DESCRIPTION
NOTES
1000 99 007 GROMMET SOLAR
Grommet Solar
Models: Belmont
  Comfortaire
  Delta
  Royal





Used Between heater and wall to minimise vibration.
1000 99 008 GUARD, RADIANT TUBE
NO IMAGE
NO LONGER AVAILABLE
1000 99 019 GROMMET,EG2A
Grommet EG2A
Models: Belmont
  Comfortaire
  Delta
  Royal

Used between motor and motor bkt. to minimise vibration.
1000 99 030 GROMMET, FLEXIBLE FG2.4
NO IMAGE

1000 99 031 O-RING, RUBBER
O-Ring, Rubber
Models: Odyssey

Used on lid hinges
3000 01 001 ELEMENT,2.4KW
NO IMAGE
NO LONGER AVAILABLE
3000 01 002 ELEMENT,3.5KW
Element 3.5KW
Models: FH8 Alpha
  FH7 Highmount

Main heating element

NO LONGER AVALIABLE
3000 01 004
KIT,MICROTEMP CONVERSION
KIT. MICROTEMP CONVERSION
Models: FH8 Alpha

Replaces old bi-metal resettable overloads.

NO LONGER AVALIABLE
3000 01 009 SH804 SWITCH CONV.KIT
NO IMAGE
NO LONGER AVAILABLE
3000 05 001 FAN BLADE
NO IMAGE
NO LONGER AVAILABLE
3000 06 001 PILOT LIGHT SH37
PILOT LIGHT SH37
Models: Comfortaire
  FM3 Belmont
  Delta
  FH8 Alpha
  FM5 Royal
  Odyssey
  Timerbox

Main indicator light in red colour.
3000 10 001 MOTOR.SH805
NO IMAGE
NO LONGER AVAILABLE
3000 11 001 SWITCH, HEAT SH809
SWITCH. HEAT SH809
Models: FH8 Alpha

1-2-3-4 Heat setting selector
3000 11 002 SWITCH, FAN SH804
NO IMAGE
NO LONGER AVAILABLE
3000 16 001 THERMOSTAT, SH17A
THERMOSTAT, SH17A
Models: Comfortaire
  FM3 Belmont
  Delta
  FM5 Royal

Main control t/stat. Obtain serial and model numbers for more accurate assessment.
3000 16 002 MICROTEMP, 93 DEGREES
MICROTEMP, 93 DEGREES
Models: Comfortaire
  FM3 Belmont
  Delta
  FM5 Royal
  FH8 Alpha
  FH7 Highmount

Thermal overload protection.

NO LONGER AVALIABLE
3000 18 004 KNOB, SH48-BROWN
KNOB, SH48-BROWN
Models: Comfortaire
  FM3 Belmont
  Delta
  FM5 Royal
  FH8 Alpha

Control knob. Generally fits most switches. Number inside knob shaft can help identify knob req.
3000 18 005 KNOB SH 808 ALPHAS
KNOB SH 808 ALPHAS
Models: FH8 Alpha

Control knob. Fits SH804 & SH809 switch. Number inside knob shaft can help identify knob req.

NO LONGER AVALIABLE
3000 20 001 TIMER 3HR TS4015A
TIMER 3HR TS4015A
Models: Comfortaire
  Belmont
  Alpha
  Timerbox

3hr wind back timer.

NO LONGER AVAILABLE
3000 20 002 TIMER 3HR ITALORA 50 IT/ITS
TIMER 3HR ITALORA 80
Models Alpha
  Timerbox

: 3hr wind back timer.
3000 21 001 T/BLOCK - 12 POSITION
T/BLOCK - 12 POSITION
Models: Numerous models

Available in different lengths.
3000 99 004 WAFER, CERAMIC
WAFER, CERAMIC
Models: Numerous models

Element support. Used on all Pureheat manufactured elements.
3000 99 005 BUSH CERAMIC
BUSH CERAMIC
Models Numerous models

: Used on various terminal applications.
3100 01 001 ELEMENT, 4.75KW
NO IMAGE
NO LONGER AVAILABLE
3100 01 002 ELEMENT, 3.1KW
NO IMAGE
NO LONGER AVAILABLE
3100 01 006 ELEMENT, 6KW
NO IMAGE
NO LONGER AVAILABLE
3100 01 007 KIT, M/TEMP CONV.
NO IMAGE
NO LONGER AVAILABLE
3100 01 008 KIT, M/TEMP CONV.
NO IMAGE
NO LONGER AVAILABLE
3200 01 003 ELEMENT, 4.75KW
ELEMENT, 4.75KW
Models: Comfortaire
  FM3 Belmont
  FM5 Royal

Main heating element. Used on superceded versions. This element is slightly different to elements manufactured since 1999-2000.

3200 02 001 BRACKET, MOTOR SH09
BRACKET, MOTOR SH09
Models: Comfortaire
  FM3 Belmont
  FM5 Royal

SH09 motor mounts to this bracket on numerous superceded models.

NO LONGER AVALIABLE
3200 04 002 FRONT COVER
NO IMAGE
NO LONGER AVAILABLE
3200 04 003 GRILL
NO IMAGE
NO LONGER AVAILABLE
3200 10 001 MOTOR SH09
MOTOR SH09
Models: Comfortaire
  Belmont
  Delta
  Royal

Main motor.
Can be used on superceded models which used black round version but will need a slight bracket adjustment.
3200 11 001 SWITCH, SH35 HEAT
NO IMAGE
NO LONGER AVAILABLE
3200 11 002 RELAY
RELAY
Models: Comfortaire
  Alpha
  Belmont
  Odyssey
  Royal

Main relay.
3200 11 003 SWITCH, PWD 16
NO IMAGE
NO LONGER AVAILABLE
3200 16 003 OTTER, SPEED, SH 61
OTTER, SPEED, SH 61
Models: Comfortaire
  FM3 Belmont
  Delta
  FM5 Royal

Drops speed of motor on selected models when pre-selected temperature has been reached.
3200 20 001 TIMER 12HR SH40
TIMER 12HR SH40
Models: Comfortaire
  FM3 Belmont
  FM5 Royal

12 hr to ON wind back timer
3200 24 001 RESISTOR, SP/DROP 750 OHM
RESISTOR, SP/DROP 750 OHM
Models: Comfortaire
  FM3 Belmont
  Delta
  FM5 Royal

Resistor which is used in conjunction with p/n 3200 16 003 to help reduce fan speed.
3250 02 001 BRACKET, FRONT SUPPORT
BRACKET, FRONT SUPPORT
Models: Belmont
  Royal

Support brace.
3250 04 001 FRONT PANEL - BELMONT
FRONT PANEL - BELMONT
Models: Belmont

Main front panel in white colour
3250 06 001 PILOT LIGHT - ENERGY SAVER
PILOT LIGHT - ENERGY SAVER
Models: Belmont

Red pilot light used on selected heaters in the Belmont range - rocker switch size.
3250 08 001 BADGE, BELMONT ROUND
BADGE, BELMONT ROUND
Models: Belmont

Used on top switch panel
3250 11 001 SWITCH, ROCKER - NO IND. LGT
SWITCH ROCKER - NO IND. LGT
Models: Belmont

Rocker switch with no indicator light used on selected heaters in Belmont range.
3300 01 001 ELEMENT, 4.75KW
ELEMENT, 4.75KW
Models: Delta

Main heating element.

NO LONGER AVAILABLE
3300 01 002 KIT, MICROTEMP CONVERSION
KIT, MICROTEMP CONVERSION
Models: Delta

Replaces old bi-metal resettable overloads

NO LONGER AVALIABLE
3300 01 003 ELEMENT, 6KW
ELEMENT, 6KW
Models: Delta

Main heating element..

NO LONGER AVALIABLE
3300 04 002 COVER, FRONT
NO IMAGE
NO LONGER AVAILABLE
3300 04 003 GRILL
NO IMAGE
NO LONGER AVAILABLE
3300 05 001 FAN BLADE
FAN BLADE
Models: Comfortaire
  Belmont
  Delta
  Royal

Main fan blade.
Fits to SH09 motor (p/n 3200 10 001)
3300 08 001 ESCUTCHEON, LIT-20
NO IMAGE
NO LONGER AVAILABLE
3350 01 002 POTENTIOMETER / LOOM ASS.
POTENTIOMETER
Models: Odyssey

Main control loom assy.
For electronic Odyssey versions only.

NO LONGER AVAILABLE
3350 01 004 TRIAC PCB & HEATSINK ASSY
TRIAC PCB & HEATSINK ASSY
Models: Odyssey

Triac/heatsink Assy.
For electronic Odyssey versions only.

NO LONGER AVAILABLE
3350 02 001 STANDOFF, P.C.B.
STANDOFF, P.C.B.
Models: Odyssey


NO LONGER AVALIABLE
3350 02 002 MOUNT, L.E.D.
MOUNT L.E.D.
Models: Odyssey

LED mount.
Used with p/n 3350 06 001.
For electronic Odyssey versions only.

NO LONGER AVAILABLE
3350 04 002 ODYSSEY FRONT PANEL
ODYSSEY FRONT PANEL
Models: Odyssey

Main front panel in white colour.
3350 04 003 ODYSSEY SIDE MOULDING
ODYSSEY SIDE MOULDING
Models: Belmont
  Odyssey
  Royal

Side moulding in white colour.
3350 04 004 ODYSSEY CONSOLE MOULDING
ODYSSEY CONSOLE MOULDING
Models: Odyssey

Charcoal top console, used on timer versions only.
3350 04 005 ODYSSEY LID MOULDING
ODYSSEY LID MOULDING
Models: Odyssey

Lid in white colour.
3350 04 006 ODYSSEY SIDE MOULDING - BLACK
ODYSSEY SIDE MOULDING - BLACK
Models: Belmont
  Odyssey
  Royal

Side moulding in black colour.

NO LONGER AVAILABLE
3350 04 007 ODYSSEY LID MOULDING - BLACK
ODYSSEY LID MOULDING - BLACK
Models: Odyssey

Lid moulding in black colour.

NO LONGER AVAILABLE
3350 04 008 ODYS. FRONT PANEL - S/STEEL
ODYS. FRONT PANEL - S/STEEL
Models: Odyssey

Front panel in stainless steel.

NO LONGER AVAILABLE
3350 04 009 ODYSSEY GRILL
ODYSSEY GRILL
Models: Odyssey

Heat outlet grill in black colour.
3350 04 011 ODYSSEY CONSOLE, NO-TIMER
ODYSSEY CONSOLE, NO-TIMER
Models: Odyssey

Charcoal top console - used on NON-timer versions.
3350 05 001 FAN BARREL (TORIN MOTORS)
FAN BARREL
Models: Alpha
  Highmount
  Odyssey

Used on Torin branded motors.

NO LONGER AVAILABLE
3350 06 001 L. E. D. - BLUE
L.E.D. BLUE
Models: Odyssey

Blue L.E.D, main pilot light.
For electronic Odyssey versions only.

NO LONGER AVAILABLE
3350 06 002 PILOT LIGHT - GREEN
PILOT LIGHT - GREEN
Models:
Odyssey - ECO Version

Main indicator light in green colour. Used on ECO Version

NO LONGER AVAILABLE
3350 10 001 2.4KW FAN/MOTOR / ELE ASSY (TORIN)
2.4KW FAN/MOTOR
Models: Alpha
  Highmount
  Odyssey

Branded Torin, 2 speed.

NO LONGER AVAILABLE
3350 10 002 3.5KW FAN/MOTOR / ELE ASSY (TORIN)
3.5KW FAN/MOTOR
Models: Alpha
  Highmount
  Odyssey

Branded Torin, 2 speed.

NO LONGER AVAILABLE
3350 10 003 4.5KW FAN/MOTOR / ELE ASSY (TORIN)
4.5KW FAN/MOTOR
Models: Alpha
  Highmount
  Odyssey

Branded Torin.

NO LONGER AVAILABLE
3350 10 004 MOTOR/FAN, 2.4/3.5KW
MOTOR/FAN 2.4/3.5KW
Models: Alpha
  Highmount
  Odyssey

Branded Torin, 2 speed.

NO LONGER AVAILABLE
3350 10 005 MOTOR/FAN, 4.5KW
MOTOR/FAN 4.5 KW
Models: Alpha
  Highmount
  Odyssey

Branded Torin, 2 speed.

NO LONGER AVAILABLE
3350 10 006 MOTOR ONLY - TO SUIT 4.5KW TORIN
MOTOR ONLY - TO SUIT 4.5KW TORIN
Models: Alpha
  Highmount
  Odyssey

Branded Torin, 2 speed.
3350 10 007 MOTOR ONLY - TO SUIT 2.4/3.5KW TORIN
MOTOR ONLY - TO SUIT 2.4/3.5 TORIN
Models: Alpha
  Highmount
  Odyssey

Branded Torin, 2 speed.
3350 16 002 THERMOSTAT, POTENTIOMETER
THERMOSTAT, POTENTIOMETER
Models: Odyssey

Main control. For electronic Odyssey versions only.

NO LONGER AVALAIBLE
3350 16 003 SENSOR, THERMAL
SENSOR, THERMAL
Models: Odyssey

Main heat sensor. For electronic Odyssey versions only.

NO LONGER AVALAIBLE
3350 17 001 ELEMENT 4.5KW (TORIN)
ELEMENT 4.5KW
Models: Odyssey
  Alpha
  Highmount

NO LONGER AVALAIBLE
3350 17 002 2.4KW ELEMENT (TORIN)
2.4KW ELEMENT
Models: Odyssey
  Alpha
  Highmount

Fits Torin branded motor.
Serial number may help identify model.

NO LONGER AVALAIBLE
3350 17 003 3.5KW ELEMENT (TORIN)
3.5KW ELEMENT
Models: Odyssey
  Alpha
  Highmount

Fits Torin branded motor.
Serial number may help identify model.

NO LONGER AVALAIBLE
3350 18 001 KNOB, ODYSSEY
KNOB ODYSSEY
refer pin 3450 18 001
3350 20 001 TIMER, GRASSLIN BLK/YELLOW
TIMER, GRASSLIN BLK/YELLOW
refer pin 3450 20 001
3350 21 001 TERMINAL BLOCK
TERMINAL BLOCK
Models: Odyssey

Main terminal block.
For electronic Odyssey versions only.

NO LONGER AVALAIBLE
3350 23 001 CORD & PLUG, 2.9 MTR GREY
CORD & PLUG
Models: Odyssey

Main flex & plug. 2.4kw models only
3350 25 001 P.C.B. FOR 4.5 KW
P.C.B. FOR 4.5KW
Models: Odyssey

Main printed circuit board.
For electronic Odyssey versions only
3350 25 002 TRIAC
TRIAC
Models: Odyssey

Triac
For electronic Odyssey versions only.
3350 25 003 P.C.B. FOR 2.4 & 3.5 KW
P.C.B. FOR 2.4 & 3.5KW
Models: Odyssey

Main printed circuit board.
For electronic Odyssey versions only.
3350 99 008 NYLON BEARING (TORIN)
NYLON BEARING (TORIN)
Models Odyssey
  Alpha
  HIghmount

Nylon bearing used on Torin branded motor/fans.

NO LONGER AVAILABLE
3400 01 001 FRONT ASSEMBLY
NO IMAGE
NO LONGER AVAILABLE
3400 01 003 ELEMENT, 2.4KW
ELEMENT 2.4KW
Models: Comfortaire
  FM3 Belmont
  FM5 Royal

Main heating element.
Used on superceded versions.
This element is slightly different to elements manufactured since 1999-2000.
3400 01 005 ELEMENT, 3.5KW
ELEMENT, 3.5KW
Models: Comfortaire
  FM3 Belmont
  FM5 Royal

Main heating element.
Used on superceded versions.
This element is slightly different to elements manufactured since 1999-2000.
3400 01 006 ELEMENT, 4.75KW
ELEMENT, 4.75KW
Models: Comfortaire
  FM3 Belmont
  FM5 Royal

Main heating element.
Used on superceded versions.
This element is slightly different to elements manufactured since 1999-2000.
3400 01 007 ELEMENT, 6KW
ELEMENT, 6KW
Models: Comfortaire
  FM3 Belmont
  FM5 Royal

Main heating element.
Used on pre 1999-2000 models.
Serial number may help identify.
3400 01 008 KIT MICROTEMP CONVERSION
KIT, MICROTEMP CONVERSION
Models: Comfortaire
  FM3 Belmont
  FM5 Royal

Replaces old bi-metal resettable overloads.

NO LONGER AVAILABLE
3400 01 014 SWITCH CONV. KIT - SH35
SWITCH CONV. KIT SH35
Models: Comfortaire
  FM3 Belmont
  Delta
  FM5 Royal

Replaces off-heat-fan switch used on pre 1999-2000 models.

NO LONGER AVAILABLE
3400 04 005 REFLECTOR
REFLECTOR
Models: FM5 Royal

Used on pre 1999-2000 models.

NO LONGER AVALIABLE
3400 04 006 REFLECTOR END. R/H
REFLECTOR END. R/H/
Models: FM5 Royal

Used on pre 1999-2000 models.

NO LONGER AVALIABLE
3400 04 007 REFLECTOR END L/H
REFLECTOR END L/H
Models: Royal

Used on pre 1999-2000 models.

NO LONGER AVALIABLE
3400 04 008 CHANNEL, TOP
CHANNEL, TOP
Models: Royal

Used on pre 1999-2000 models.

NO LONGER AVALIABLE
3400 04 009 CHANNEL, BOTTOM
CHANNEL, BOTTOM
Models: FM5 Royal

Used on pre 1999-2000 models.

NO LONGER AVALIABLE
3400 08 001 ESCUTCHEON FW5
NO IMAGE
NO LONGER AVAILABLE
3400 11 001 SWITCH, SH36 RADIANT
NO IMAGE
Refer P/N 3450 01 009
3400 17 002 SH51A RADIANT TUBES
SH51A RADIANT TUBES
Models: FM5 Royal

Radiant element. Used on pre 1999-2000 models.

NO LONGER AVALIABLE
3400 99 001 CANDLES, CERAMIC
CANDLES, CERAMIC
Models: FM5 Royal

Sits in front off radiant elements on pre 1999-2000 models.
3450 01 001 3.5KW ELEMENT ASSY
3.5KW ELEMENT ASSY
Models: 3250 Series Belmont
  3450 Series Royal

Main heating element.
Used on models POST 1999-2000.
3450 01 002 4.75KW ELEMENT ASSY
4.75KW ELEMENT ASSY
Models: 3250 Series Belmont
  3450 Series Royal

Main heating element.
Used on models POST 1999-2000.
Serial number may help identify.
3450 01 003 6.0KW ELEMENT ASSY
6.0KW ELEMENT ASSY
Models: 3250 Series Belmont
  3450 Series Royal

Main heating element.
Used on models POST 1999-2000.
Serial number may help identify.
3450 01 007 OVERLOAD/BGR ASSY
OVERLOAD/BGR ASSY
Models: 3250 Series Belmont
  3450 Series Royal

Main thermal overload.
2 used per unit.
Used on models POST 1999-2000.
3450 01 009 SWITCH CONV. KIT - SH36
SWITCH CONV. KIT - SH36
Models: FM5 Royal

Radiant conversion kit used to replace p/n 3400 11 001 on Royals pre 1999-2000.

NO LONGER AVAILABLE
3450 02 017 SIDE, REFLT-INNER, NEWROY
SIDE, REFLT - INNER, NEWROY
Models: 3450 Series Royal

Used on radiant heat section. Used on models POST 1999-2000.

NO LONGER AVAILABLE
3450 02 018 SIDE, REFL, - OUTER, NEWROY
SIDE, REFL - OUTER, NEWROY
Models: 3450 Series Royal

Used on radiant heat section. Used on models POST 1999-2000.

NO LONGER AVAILABLE
3450 04 002 BELMONT CONSOLE - WHITE
BELMONT CONSOLE - WHITE
Models: 3250 Series Belmont
  3450 Series Royal

Main console control panel.
3450 04 008 CHAMBER, FAN - NEW ROYAL
CHAMBER, FAN - NEW ROYAL
Models: 3250 Series Belmont
  3450 Series Royal

Main fan chamber.
3450 04 009 GRILL, LOWER - NEW ROYAL
GRILL, LOWER - NEW ROYAL
Models: 3250 Series Belmont
  3450 Series Royal

Main console control panel.
3450 11 001 SWITCH ROCKER
SWITCH ROCKER
Models: 3250 Series Belmont
  3450 Series Royal
  Odyssey

Main on-off control - red.
3450 11 002 RADIANT SWITCH
RADIANT SWITCH
Models: 3450 Series Royal

Main radiant control switch.
3450 16 004 T/STAT
T/STAT
Models: 3250 Series Belmont
  Odyssey
  3450 Series Royal

Main control thermostat
3450 17 001 RADIANT TUBE
RADIANT TUBE
Models: 3450 Series Royal

Radiant element with leads.

NO LONGER AVAILABLE
3450 18 001 KNOB, THERMOSTAT
KNOB, THERMOSTAT
Models: AL Series Alpha
  3250 Series Belmont
  Odyssey
  3450 Series Layout

Thermostat control knob.
3450 01 010 ROYAL KNOB, RADIANT
ROYAL KNOB, RADIANT
Models: 3450 Series Royal

Radiant control know c/w steel clip attached to the shaft.
3450 20 001 TIMER, GRASSLIN BLK/WHT
TIMER, GRASSLIN BLK/WHT
Models 3250 Series Belmont
  Odyssey
  3450 Series Royal

24hr timer - each tab is equal to 15 minutes.
3450 99 003 MICA PAPER, GRADE 505-3
NO IMAGE

3500 01 016 MICROTEMP LINK ASSY
MICROTEMP LINK ASSY
Models: AL Series Alpha
  HM Series Highmount
  Odyssey

Microtemp assy which fits selected 2.4 & 3.5kW elements.
3500 01 017 MICROTEMP LINK ASSY
MICROTEMP LINK ASSY
Models: AL Series Alpha
  HM Series Highmount
  Odyssey

Microtemp assy which fits selected 4.5kW elements.
Serial number may help identify.
3500 01 019 ALPHA ELEMENT CONV. KIT - 2.4KW
ALPHA ELEMENT CONV. KIT - 2.4KW
Models: Odyssey
  AL Series Alpha
  HM Series Highmount

To replace elements with inbuilt un-replaceable microtemps.
These fit to fergas branded motors.

NO LONGER AVAILABLE
3500 01 020 ALPHA ELEMENT CONV. KIT - 3.5KW
ALPHA ELEMENT CONV. KIT - 3.5KW
Models: Odyssey
  AL Series Alpha
  HM Series Highmount

To replace elements with inbuilt un-replaceable microtemps.
These fit to fergas branded motors.

NO LONGER AVAILABLE
3500 01 023 BRG ASSY TO SUIT TORIN
BRG ASSY TO SUIT TORIN
Models: AL Series Alpha
  HM Series Highmount

To replace thermal overloads used on selected torin branded motor/elements.

NO LONGER AVAILABLE
3500 04 006 EXTRUSION, GRILL
EXTRUSION, GRILL
Models: AL Series Alpha
  HM Series Highmount

Heat inlet and outlet grill.
3500 06 001 PILOT LIGHT
PILOT LIGHT
Models: AL Series Alpha

Main indicator light.
3500 06 002 LENS, RED PILOT LIGHT
LENS, RED PILOT LIGHT
Models: AL Series Alpha

Main indicator lens. Fits p/n 3500 06 001
3500 10 001 MOTOR/FAN (15 MM)
MOTOR/FAN (15 MM)
Models: Odyssey
  AL Series Alpha
  HM Series Highmount

Branded Fergas to suit 2.4 & 3.5kW elements.
Can be used on selected models.
3500 10 002 MOTOR/FAN (20 MM)
MOTOR/FAN (20 MM)
Models: Odyssey
  AL Series Alpha
  HM Series Highmount

Branded Fergas to suit 2.4 & 3.5kW elements.
Can be used on selected models.
Serial number may help.
3500 11 001 SWITCH, ROTARY
SWITCH, ROTARY
Models: AL Series Alpha

Main control switch
3500 16 001 THERMOSTAT - SH72
THERMOSTAT - SH72
Models: AL Series Alpha
  HM Series Highmount

Main thermostat.
Locks in with p/n 3500 11 001 or can be used by itself.
3500 16 004 BI-METAL O/LOAD
BI-METAL O/LOAD
Models: AL Series Alpha
  HM Series Highmount
  Odyssey

Self resetting bi-metal overload.
Fits Torin & BJC branded elements.
3500 17 001 ELEMENT, 2.4KW
ELEMENT, 2.4KW
Models: AL Series Alpha
  HM Series Highmount
  Odyssey

Main heating element.
Suitable for Fergas branded motors.
3500 17 002 ELEMENT, 3.5KW
ELEMENT, 3.5KW
Models: AL Series Alpha
  HM Series Highmount
  Odyssey

Main heating element.
Suitable for Fergas branded motors.
3500 17 004 ELEMENT, 4.5KW
Models: AL Series Alpha
  HM Series Highmount
  Odyssey

Main heating element.
Suitable for Fergas branded motors.
3500 18 001 ALPHA KNOB, HEAT
ALPHA KNOB, HEAT
Models: AL Series Alpha

Main heat control knob.
Fits p/n 3500 11 001
3500 18 002 KNOB, TIMER
KNOB, TIMER
Models: AL Series Alpha
  3250 Series Belmont

3hr to off timer knob.
Fits to p/n 3000 20 001
3500 18 003 KNOB, THERMOSTAT
KNOB, THERMOSTAT
Refer p/n 3450 18 001
3500 23 001 LEAD & PLUG, 1 RING
LEAD & PLUG, 1 RING
Models: Alpha

Main flex & plug
Suits 2.4KW models only.
3550 04 003 PANEL, FRONT
PANEL, FRONT
Models: HM Series Highmount

Main front panel in white colour.
3600 01 003 ELEMENT CONV. KIT
NO IMAGE
NO LONGER AVAILABLE
3600 10 001 MOTOR, TS4021
MOTOR, TS4021
Models: Midibank

2.4kw fan/motor/element assy.
For auxillary boost on selected midibank models.

NO LONGER AVAILABLE
3600 11 001 SWITCH, ROCKER
SWITCH, ROCKER
Models: Midibank

Auxillary rocker switch.
3600 16 001 CORE CONTROL (4.5KW)
CORE CONTROL (4.5KW)
Models Midibank

Main core thermostat.

NO LONGER AVAILABLE
3600 16 002 THERMAL FUSE, 192 DEG
THERMAL FUSE, 192 DEG
Models: Midibank

Microtemp used on side of midibank.
3600 16 003 THERMAL FUSE, 77 DEG
THERMAL FUSE, 77 DEG
Models: Midibank

Microtemp used on auxillary boost assy.

NO LONGER AVAILABLE
3600 16 004 CORE CONTROL (2.4KW)
CORE CONTROL (2.4KW)
Models: Midibank

Main core thermostat

NO LONGER AVAILABLE
3600 17 001 ELEMENT, 4.5KW
NO IMAGE
NO LONGER AVAILABLE
3600 17 002 ELEMENT, 2.5KW
NO IMAGE
NO LONGER AVAILABLE
3600 18 001 KNOB, CORE CONTROL
NO IMAGE
NO LONGER AVAILABLE
3600 21 001 T/BLOCK, CERAMIC
NO IMAGE
NO LONGER AVAILABLE
3600 00 001 TIMER BOX, HM7A
NO IMAGE
NO LONGER AVAILABLE
3800 04 001 COVER, 1 HOLE
COVER, 1 HOLE
Models: Timerbox

Cover to suit HM7B
3800 04 003 COVER, 2 HOLE
NO IMAGE
NO LONGER AVAILABLE
3800 16 001 THERMOSTAT, SH72
THERMOSTAT, SH72
Models: Timerbox

Main thermostat with stopper.
3800 18 001 KNOB, P/N P7026
KNOB, P/N P7026
Models: Timerbox

Timer knob.
3850 02 002 BRACKET, LONG WALL
NO IMAGE
NO LONGER AVAILABLE
3850 04 005 REFLECTOR
NO IMAGE
NO LONGER AVAILABLE
